MP-A250B is a digital amplier with 2 analog and 1 optical inputs. 2 analog and 1 optical digital inputs. Bass, Treble & Volume adjustable. Stereo and bridge output modes selectable.

Features:

2 analog and 1 optical digital inputs
Stereo and bridge output modes selectable
Bass, Treble & Volume adjustable
Loop output to cascade to another amplifier.
Locking power connector.
Controllable via button, RS232, IR, and TCP/IP

Specification

Video Inputs	2 stereo (L+R RCA, 3.5mm jack) >10K Ω 1 digital audio(SPDIF fiber connector)
Audio Output	1 amplifier (4P captive screw connector) 1 stereo loop out (3.5mm jack)
Output Type	Constant resistance 4Ω/8Ω
Power Output	2x50W / 1x100W (bridge)
Voltage Gain	32dB
Frequency Response	20Hz~20KHz
CMRR	>80dB@20Hz to 20KHz
SNR	85dB(Max)
Stereo Channel Separation	>80dB@20Hz to 20KHz
Bandwidth	20Hz~25KHz
THD + Noise	<0.01% @1KHz
Control	Button, RS232, TCP/IP, optional IR remote
Power Supply	DC33V, 4A
Chassis Dimension	W148xH44xD160mm
