| DL-BR 15-100/T (For Universal Use! -Metal Ceiling Speakers) |
 |
| The DL-BR 15-100/T plus are compact ceiling speakers, providing full, high quality sound for background music.
These special IC audio speakers are ideally suited for a wide variety of applications, from restaurants, coffee shops, offices and retail stores to airports. |
| Features : |
 Low distortion and a smooth, natural frequency response make the DL-BR series ideal for medium volume business music systems as well as for the medium to low SPL segments of larger or louder systems. |
| The Installation of the DL-BR speakers is quick and easy. The entire installation can be accomplished without requiring access above the ceiling and is additionally relieved by a suspension. The connection is easily done by a pluggable clamp. After mounting you can adjust the power conveniently at the front of the speakers. |
| 2-way technology with balanced frequency range. |
| All DL-BR Speakers are serially equipped with a strain-relief. |
| Robust ABS Housing. |
|
| Technical Specifications: |
| Technical Specifications |
DL-BR 15-100/T |
| Power |
15 / 7.5 / 3.75 / 1.9W |
| Frequency Range |
85-23000 Hz |
| SPL 1W / 1m |
90.9dB |
| SPL Pmax / 1m |
102.6dB |
| Dimensions |
190 X 135mm |
| Ceiling Cut-out |
168mm |
| Temperature Range |
-200 to +800C |
| Dispersion Angle (-10dB) |
1700 (H) / 1700 (V) |
| Weight |
1.63 Kg. |
| Mounting |
Screws |
| Colour |
RAL 9010 |
|
| |
