| Rated Input |
6 W (100 V line), 3 W (70 V line) |
| Rated Impedance |
100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 6.7 kΩ (1.5 W), 13 kΩ (0.8 W)
70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 6.7 kΩ (0.8 W), 13 kΩ (0.4 W) |
| Sensitivity |
94 dB (1 W, 1 m) (500 Hz - 5 kHz, pink noise) |
| Frequency Response |
150 Hz - 20 kHz (peak -20 dB) |
| Speaker Component |
16 cm (6") double cone-type |
| Applicable Cable |
600 V vinyl-insulated cable (IV wire or HIV wire)
Solid wire: f0.8 - f1.6 mm (equivalent to AWG 20 - 14)
7-core twisted wire: 0.75 - 1.25 m? (equivalent to AWG 18 - 16) |
| Connection |
Push-in connector (bridging terminal) |
| Finish |
Baffle: HIPS, off-white (RAL 9010 or equivalent color)
Cabinet: Particle board with pvc sheet, off-white (RAL 9010 or equivalent color)
Grille: Surface-treated steel plate net, off-white (RAL 9010 or equivalent color) |
| Dimensions |
250 (W) × 190 (H) × 110 (D) mm (9.84" × 7.48" × 4.33") |
| Weight |
1.7 kg (3.75 lb) |
| Accessory |
Speaker mounting screw (4 × 35 (0.16" × 1.38")) …2 |
