| Rated Input |
10 W |
| Rated Impedance |
100 V line: 1 kΩ (10 W), 2 kΩ (5 W), 3.3 kΩ (3 W), 10 kΩ (1 W)
70 V line: 500 Ω (10 W), 1 kΩ (5 W), 2 kΩ (2.5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W) |
| Sensitivity |
90 dB (1 W, 1 m) |
| Frequency Response |
120 - 20,000 Hz |
| Speaker Component |
Low frequency: 12 cm (5") cone-type, High frequency: Balanced dome-type |
| Input Connector |
M4 screw terminal, distance between barriers: 11 mm (0.43") |
| Finish |
Enclosure: HIPS resin (fire resistant grade UL94 V-0 or its equivalent), silver
Net: Steel plate, silver, paint |
| Dimensions |
210 (W) × 330 (H) × 80 (D) mm (8.27" × 12.99" × 3.15") |
| Weight |
1.4 kg (3.09 lb) |
| Accessory |
Speaker receptacle …1, Wall mounting screw …2 |
|
