| Enclosure |
Bass-reflex type |
| Power Handling Capacity |
Continuous pink noise: 200 W, Continuous program: 600 W |
| Rated Impedance |
8 Ω |
| Sensitivity (1 W, 1 m) |
96 dB (60? mode), 97 dB (45? mode), 98 dB (30? mode), 99 dB (15? mode) |
| Frequency Response |
70 Hz - 20 kHz (-10 dB) (60%%d mode), 75 Hz - 20 kHz (-10 dB) (45%%d mode),
80 Hz - 20 kHz (-10 dB) (30%%d mode), 85 Hz - 20 kHz (-10 dB) (15%%d mode) |
| Crossover Frequency |
4 kHz |
| Directivity Angle |
Horizontal: 100? (2 kHz or more)
Vertical: 60? (800 Hz or more), 45? (1.2 kHz or more), 30? (1.6 kHz or more),
15? (3.2 kHz or more) variable |
| Speaker Component |
Low frequency: 12 cm cone-type × 4, High frequency: Balanced dome-type × 12 |
| Input Terminal |
SpeakΩ n NL4MP × 2 and M4 screw terminal |
| Finish |
Enclosure: Polypropylene, black
Punched net: Surface-treated steel plate, black |
| Dimensions |
408 (W) × 546 (H) × 342 (D) mm |
| Weight |
16 kg |
| Accessory |
Hanging bracket …2, Hex. wrench …1 |
| Option |
Matching transformer: MT-200
Speaker mounting bracket: HY-PF1B, HY-CW1B, HY-WM1B, HY-WM2B, HY-CN1B
Speaker stand adapter: HY-ST1 |
|
