| Rated Input |
6 W (100 V line), 3 W (70 V line) |
| Rated Impedance |
100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 6.7 kΩ (1.5 W), 13 kΩ (0.8 W)
70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 6.7 kΩ (0.8 W), 13 kΩ (0.4 W) |
| Sensitivity |
94 dB (1 W, 1 m) (500 - 5,000 Hz, pink noise) |
| Frequency Response |
40 - 20,000 Hz (peak -20 dB) |
| Speaker Component |
20 cm (8") double cone-type |
| Dimensions for Fixing Hole |
Mounting hole: f250±3 mm (f9.84"±0.12")
Ceiling thickness: 5 - 25 mm (0.2" - 0.98") |
| Speaker Mounting Method |
Spring clamp |
| Applicable Cable |
600 V vinyl-insulated cable (IV wire or HIV wire)
Solid copper wire: f0.8 - f1.6 mm (equivalent to AWG 20 - 14)
7-core twisted copper wire: 0.75 - 1.25 m? (equivalent to AWG 18 - 16) |
| Connection |
Push-in connector (bridging terminal-2 branch type |
| Finish |
Baffle: Steel plate, off-white (RAL 9010 or equivalent color), paint
Grille: Surface-treated steel plate net, off-white (RAL 9010 or equivalent color),
paint |
| Dimensions |
f280 × 92 (D) mm (f11.02" × 3.62") |
| Weight |
1.4 kg (3.09 lb) |
| Accessory |
Paper pattern …1 |
