| Enclosure |
Bass-reflex type |
| Power Handling Capacity |
Continuous program: 450 W |
| Rated Impedance |
8 Ω |
| Sensitivity |
93 dB (1 W, 1 m) |
| Frequency Response |
40 - 400 Hz (when driven with the optional DP-0206's recommended parameters*) |
| Crossover Frequency |
125 Hz (when driven with the optional DP-0206's recommended parameters*) |
| Speaker Component |
38 cm (15") cone-type |
| Input Connector |
M5 screw terminal, distance between barriers: 12.2 mm (0.48")
and Neutrik NL4MP × 2 |
| Finish |
Enclosure: Plywood, black, urethane paint
Front grille: Punched steel plate, black, paint |
| Dimensions |
526.6 (W) × 594.8 (H) × 550 (D) mm (20.73" × 23.42" × 21.65") |
| Weight |
41 kg (90.39 lb) |
| Accessory |
M8 connection bolt …4 |
| Option |
Rigging frame: SR-RF8
Digital processor: DP-0206*
Digital Mixer: D-901
Digital Mixing Processor Unit: D-2008SP |
